Model No.︰SHCDCS-200
Brand Name︰SHOOT
Country of Origin︰China
Unit Price︰US $ 28000 / pc
Minimum Order︰1 pc
| Center Dust Collector System | |
| Model | SHCDCS-200 |
| Machine motor power | 15kw,150cv 1500rpm |
| Motor Weight | 650kg |
| Max. Air Speed | 20000m3 |
| Min. Air Speed | 15570m3 |
| Labor rate | 1.86/m3/min/m2 |
| Filtre area | 200m2 |
| Speed | 27m/s |
| Air pressure | 2500pa |
| Inlet diameter | 500mm |
| Filter(dia. 280mm,high:600mm) | 15pcs |
| Bag(dia. 280mm,high:900mm) | |
| 1" Impulse Value | 5pcs |
| 5 Impulse Controller | 1pc |
| Machine's control electrical equipment | 1set |
| Machine's material | Q235 6mm |
| Machine Packing Size | 2000x2140x3500mm |
| Weight | 2500kg |
| Please Notice | |
| 1.Machine's price don't include pipeline cost and Install cost. | |
| 2.About pipeline cost, as following: | |
| Main pipeline diameter:500mm | |
| Assistant pipeline diameter:120mm | |
|
If main pipeline length 50m, then it can install 5pcs assistant pipeline (the end dust collector). |
|
|
cost is: a) main pipeline: USD80/m b)assistant pipeline:USD32/m |
|
Specifications︰ Supply center dust collector system for woodworking furniture factory and other factory
Export Markets︰ Asia,Africa,Middle-East
Payment Details︰ T/T,L/C at sight, Western union
Ship Date︰ 40days after receive 30% deposit
