Model No.︰SHX2-Q1,SHX2-Q2
Brand Name︰SHOOT
Country of Origin︰China
Unit Price︰US $ 650 / pc
Minimum Order︰1 pc
| Full Electric Van | |
| Model | SHX2-Q2: USD650/pc |
| Walking mode | Electric walking |
| Lifting mode | electric lifting |
| operating mode | Walking type |
| Rated load | 2000kg |
| motor power | 1000Wbrushless electric machine |
| Battery type | lead-acid cell |
| battery voltage | 48V20AH |
| controller | Sine wave vector control |
| Vehicle length | 1550mm |
| Vehicle height | 1260mm |
| width of shuttles | 685mm |
| Fork length | 1150mm |
| wheel diameter | 190mm |
| radius of turning circle | 1430mm |
| Lifting height (Max) | 190mm |
| Minimum fork height | 80mm |
| tyre type | PU foam whee |
| Dead weight (without battery) | 112kg |
| traveling speed | 6KM/h |
| hoisting speed | 7mm/s |
| rate of descent | 5mm/s |
| Maximum climb | 6°(10%) |
| Maximum steering Angle | 90° |
| Driving wheel speed | ≤120rpm |
| Brake type | E-ABS+ Magnetic brake |
| noise level | ≤75dB(A) |
| Full Electric Van | |
| Model | SHX2-Q1: USD670/pc |
| Walking mode | Electric walking |
| Lifting mode | electric lifting |
| operating mode | Walking type |
| Rated load | 2000kg |
| motor power | 1000Wbrushless electric machine |
| Battery type | lead-acid cell |
| battery voltage | 48V20AH |
| controller | Sine wave vector control |
| Vehicle length | 1550mm |
| Vehicle height | 1260mm |
| width of shuttles | 550mm |
| Fork length | 1150mm |
| wheel diameter | 190mm |
| radius of turning circle | 1430mm |
| Lifting height (Max) | 190mm |
| Minimum fork height | 80mm |
| tyre type | PU foam whee |
| Dead weight (without battery) | 108kg |
| traveling speed | 4KM/h |
| hoisting speed | 6mm/s |
| rate of descent | 4mm/s |
| Maximum climb | 6°(10%) |
| Maximum steering Angle | 90° |
| Driving wheel speed | ≤120rpm |
| Brake type | E-ABS+ Magnetic brake |
| noise level | ≤75dB(A) |
| Electric Van | |
| Model | SHX3-Q: USD500/pc |
| Rated load capacity | 3000kg |
| Driving mode | Single wheel drive 1200W |
| The fork is wide outside | 680mm/550mm |
| The inside width of the fork | 360mm/230mm |
| Fork length | 1150mm |
| Vehicle length | 1760mm |
| With/without handle | 1335mm/660mm |
| Cargo forks will be at a minimum | 85mm |
| The fork rises to the highest | 200mmm |
| Battery specification | 48V/20A[Can be increased by 32A] |
| Fork material | Cast steel |
Export Markets︰ Asia,Africa,Middle-East, South-America, North-America
Payment Details︰ T/T,L/C at sight, Western Union
Ship Date︰ 30days after receiving 30% deposit
Standard Met︰ CE
